Material around the threads in an aluminium component was breaking away during assembly and use. We describe the diagnosis, selection of inserts and their installation method.
The customer approached us with a recurring component failure, for which thread inserts for aluminium provided the solution. Material around the threads was breaking away during assembly or in service.
The problem led to more complaints, a risk of failure of the entire subassembly, and additional service and logistics costs.
Because of the design requirements, changing the material of the whole component was not an option. The solution therefore had to be found in the threaded joint itself.
The ANBI-TECH engineering team analysed the application and operating conditions of the component. We identified the main cause as insufficient strength of a thread made directly in aluminium under repeated mechanical load.
The customer faced the following consequences:
The constraint was that the component material could not be changed because of the design requirements.
Instead of seeking a substitute material for the entire component, we proposed a change where the problem occurred:
Through our own manufacturing capabilities and additional services, including installation of thread inserts, we implemented the solution comprehensively, from component modification through to production and quality inspection.
A significant increase in thread resistance to wear and pull-out.
Inserts installed in prepared holes in accordance with tolerance requirements.
The joint can be tightened and released repeatedly without degrading it.
A stabilised production process at the customer’s site, without changing the material of the entire component or redesigning the product.
In this project, the key was not manufacturing itself, but finding a technical solution that addressed the customer’s real problem.
A thread cut directly in aluminium has limited resistance to repeated tightening. A stainless-steel insert transfers the load to a higher-strength material while retaining the light weight and dimensions of the aluminium component.
This approach, combining CNC machining with technical analysis and flexibility, enables us to support customers in projects where no ready-made solution exists.
Discover ANBI-TECHImplementation was supported by complete dimensional inspection and measurement reports, in line with our working standards.
The company’s management system is based on ISO 9001, ISO 14001 and ISO 45001 certification. We take measurements, among other equipment, on an ABERLINK Axiom coordinate measuring machine.
Read our quality policy
Design requirements made it impossible to change the material of the entire component. Sometimes a change at one design interface is enough.
Send us a drawing or description of the problem and we will assess what can be done from both the technical and manufacturing perspective.
After the solution was implemented, the customer achieved:
We also machine aluminium components for other applications, as described on the CNC milling page and in the overview of aluminium alloys.
